Constructional approach "L O T U S - CLOUD"  -  for climatically hot countries




Due to frequent flooding during the rainy season, the dwellings of these climates are mostly built on stilts. The living room is thereby also a lower covered area given. To withstand occasional violent storms, the cornerstones are attached by means of ground anchors.


During my stay in India I realized that would at long-term dry / hot conditions wall insulation with cooling effect evaporator walls mind. The preparation should be cost-effective, feasible in DIY and module components - be - ie locally transportable:

Wall module frames were covered this in three differents layers: Outwardly a shiny silver or white PVC fabric covering is applied. 5 cm deep is a 2 mm thin Earth fleece to absorb water hooked into the frame. For the flow-wetting in the hot and dry months a perforated water hose is installed above on the fleece. When sprinkler hose with valve timing these are commercially available.


The inside view wall (back to 5 cm distance) is also made moist resistant, pleasing decorative fabric. Top and bottom can be adjusted the desired circulation over narrow louvers. The upward as downward flow is now to the wet (in the rainy season dry unprocessed) fleece: down to one, up and evaporating, between the fleece and the outer skin, and on the other and a cooling in the inner level, between the wet fleece and the decorative fabric.


The slight sloping roof is made with only two layers. These lead upwards into a hot-air-discharging fireplace made of matt black metal.

+ All this works without fan or pump.


Several times a year the internal fleece is to be exposed to the sun and shaken afterwards and placed again. By cleaning all surfaces and parts of unhealthy germs development is prevented.


In the Lotus cloud be taxed with solar power and solar-generated hot water generate (with tank on top of the hut) energy. Also, a biologically operating small treatment plant is recommended.





Fabric films for simple housing should have a silvery reflective side on the outside, but a dark lightproof side on the inside.



These approaches should at best also be considered before UNHCR and UNIDO for further implementation.





   ©:  Michael Thalhammer, Mumbai, Dezember 2001     aktualisiert, Wien 3.3.2016
